H-ABC Automatic vertical rotary film blowing machine

Automatic ABC Vertical Traction Rotary Film Blowing Machine is suitable for less 1000mm film.This machine is more practical than 3 layers blown film machine with horizontal traction tower.

Information Download
Inquire Now
Product Presentation
Description

The ABC Vertical Traction Rotary Film Blowing Machine mainly suitable to produce not more than 1200mm width film,and it is equipped with the vertical traction rotary device that make the film thickness more even.The ABA Vertical Traction Rotary Film Blowing Machine operation is very easy.And the safety of the ABA Vertical Traction Rotary Film Blowing machine is very high.It can be used to produce a variety of products such as packaging materials,industrial films,shrink films,and more.


Specification

Model 45/50/45-1200
Width of the film 500-1000mm
Thickness of the film 0.02-0.2mm
Output 40-200kg/h
Output According to different width, thickness of film,die size and raw material characteristics to change
Raw material HDPE LDPE LLDPE CACO3 RECYCLING
Diameter of screw Φ45/50/45
L/D ratio of screw 32:1 (With force feeding)
Gear box 146# 173# 146#
Main motor 18.5kw/22kw/18.5kw
Die diameter 100mm/250mm/300mm
